   [产品介绍]

Fused Silica Windows
High Precision Fused Silica Windows
Specifications
  Material: UV grade fused silica
Diameter Tolerance: +0.0, -0.1mm
T
hickness Tolerance: ± 0.2mm
Clear Aperture:
>80%
Parallelism:
see the table
Surface Quality:
20-10 scratch and dig
Wavefront Distortion:
l/10 per 25mm
Low Precision Fused Silica Windows
Specifications
  Material: UV grade fused silica
Diameter Tolerance:
+0.0, -0.1mm

Thickness Tolerance:
± 0.2mm
Clear Aperture:
>80%
Parallelism:
1'
Surface Quality:
60-40 scratch and dig
Wavefront Distortion:
l per 25mm


   注:我们可据客户要求加工、镀膜.
